Besides, carbonitrides precipitates MX coarse became rough and coagulated, which
reduced their hardening effect. Due to the phenomena specified, FGHAZ corresponding
to simulation-temperature interval from 900°C to 950°C had the smallest hardness. With
an increase of simulation temperature above 950°C, hardness increased due to higher
solubility of carbides.
7. CONCLUDING REMARKS
According to the investigations, the weldability of the heat resistant material P91 can
be described as very satisfactory although there is a drop in the creep resistance in the
HAZ. The investigations have shown that this drop in the creep resistance occurred in the
FGHAZ where the peak temperature reached a level of about 900-950°C. At stresses
lower than 150 MPa, the fracture location shifts from the parent steel into the softened
FGHAZ. At operating temperature of 600°C, the data points of the weldments are below
those of the parent steel by more than 25%.
This effect must be taken in account when designing the welded components made
from P91.
REFERENCES
1.
Francis, J. A., Mazur, W., Bhadeshia, H. K. D. H.,
Type IV cracking in ferritic power plant
steels,
Materials Science and Technology, 22(12): 1387-1395. (2006)
2.
Albert, S.K. et al,
Microstructural investigations on type IV cracking in a high Cr steel
, ISIJ
International, 42(12): 1497-1504. (2002)
3.
Shibli, A.,
Material Properties and Heat Treatment
, P91 Course, London. (2006)
4.
Kumar, A. et al:
Comprehensive Microstructural Characterization in Modified 9Cr-1Mo
Ferritic Steel by Ultrasonic Measurements
, Metallurgical and Materials Transactions A, 33A:
1617-1626. (2002)
5.
Kumar, A. et al:
Characterisation of Microstructure in 9% Chromium Ferritic Steels using
Ultrasonic Measurements
, Trans. Indian Inst. Met., 56(5): 483-497.(2003)
6.
Abe, F.: Effect of Fine Precipitation and Subsequent Coarsening of Fe
2
W Laves Phase on the
Creep Deformation Behaviour of Tempered Martensitic 9Cr-W Steels, Metallurgical and
Materials Transactions A, 36A: 321-332. (2005)
7.
Heuser, H., Jochum, C.,
Alloy design for similar and dissimilar welding and their behaviours
,
1
st
International Conference Super-High Strength Steels, Rome, Italy, proceedings on cd-rom.
(2005)
8.
Jallouf, S., Milović, Lj., Pluvinage, G., Carmasol, A., Sedmak, S.,
Determination of Safety
Margin and Reliability Factor of Boiler Tube with Surface Crack
, Structural Integrity and Life,
5(3): 151-162. (2005)
9.
Francis, J. A., Mazur, W., Bhadeshia, H. K. D. H.,
Estimation of type IV cracking tendency in
power plant steels
, ISIJ International, 44(11): 1966-1968. (2004)
10. Francis, J. A., Mazur, W., Bhadeshia, H. K. D. H.,
Welding procedures and Type IV
Phenomena
11. Tezuka, H., Sakurai, T., A trigger of type IV damage and a new heat treatment procedure to
suppress it. Microstructural investigations of long-term ex-service Cr-Mo steel pipe elbows,
Int. J. of Press. Vess. and Piping, 82: 165-174. (2005)
12. Milović, Lj.,
Significance of cracks in the heat-affected-zone of steels for elevated temperature
application
, Structural Integrity and Life, 8(1): 41-50. (2008)
13. Milović, Lj., Zrilić, M., Putić S.,
Primena visokohromnih čelika u termoelektranama
, 21.
međunarodni kongres o procesnoj industriji PROCESING 2008, Subotica, Serbia. (2008)
14. Milović, Lj., Momčilović, D., Putić, S., Grujić, B.,
Type IV Phenomena in Creep Resisting
Steels
, 1st International Congress of Serbian Society of Mechanics, Kopaonik, Serbia. (2007)
