3rd International Workshop on Plasticity, Damage and Fracture of Engineering Materials Book of Abstracts 4-6 October 2023 İstanbul, Türkiye Edited by Tuncay YALÇINKAYA IWPDF 2023 ISBN: 9788831482639
Edited by Tuncay Yalçınkaya The electronic version of this booklet can be found at: http://iwpdf.metu.edu.tr/ The open-source LATEX template, AMCOS_booklet, used to generate this booklet is available at https://github.com/maximelucas/AMCOS_booklet
Contents About 4 IWPDF2023 ................................... 4 Organizingcommittee............................... 5 Keynote Lectures 8 Technical Sessions 17 Co-authors List 137 Statistics......................................137 List.........................................138 Partner Institutions and Sponsors 146 Sponsors......................................146 SupportingInstitutions ..............................146 3
About IWPDF 2023 These proceedings contain the abstracts presented at the 3rd International Workshop on Plasticity, Damage and Fracture of Engineering Materials organized in a hybrid mode by Middle East Technical University in Istanbul, Türkiye. In addition to the in-person poster and oral presentations, which were broadcasted live to the online participants, the virtual pre-recorded contributions were uploaded to a YouTube channel before the meeting. Subjects of the workshop focused mainly on plasticity-damage and fracture as two main topics. Both computational and experimental studies were presented at the meting, focusing on a better understanding of how the material microstructure, loading and environmental conditions affect deformation, degradation and failure of engineering materials. The organizers wish to thank all the invited keynote lectures and the technical session contributors attending from all over the world to discuss the recent developments in the field. The papers of the workshop will be published in the Procedia Structural Integrity (Open Access). The support from Middle East Technical University, REPKON Machine and Tool Industry and Trade Inc., ESIS (European Structural Integrity Society), ESAFORM and Borçelik is gratefully acknowledged. Tuncay Yalçinkaya Chair of IWPDF 2023 4
Organizing committee Conference Chairmen Benjamin Klusemann (Leuphana University of Lüneburg, Germany) Emilio Martínez-Pañeda (University of Oxford, UK) Tuncay Yalçinkaya (Middle East Technical University, Türkiye) Local Organizing Committee Tuncay Yalçinkaya (Middle East Technical University, Türkiye) Orhun Bulut (Middle East Technical University, Türkiye) Can Erdogan (Middle East Technical University, Türkiye) Tevfik Ozan Fenercioğlu (Repkon Machine and Tool Industry and Trade Inc., Türkiye) Enes Gunay (Middle East Technical University, Türkiye) Aptullah Karakaş (Repkon Machine and Tool Industry and Trade Inc., Türkiye) Berkehan Tatli (Middle East Technical University, Türkiye) İzzet Erkin Ünsal (Middle East Technical University, Türkiye) Hande Vural (Middle East Technical University, Türkiye) Scientific Committee Farid Abed-Meraim, Arts et Métiers ParisTech (France) Ricardo Alves de Sousa, University of Aveiro (Portugal) Majid R. Ayatollahi, Iran University of Science and Technology (Iran) Ali Osman Ayhan, Sakarya University (Türkiye) Can Ayas, Delft University of Technology (The Netherlands) C. Can Aydinder, Bogazici University (Türkiye) Lorenzo Bardella, Università degli Studi di Brescia (Italy) Laurence Brassart, University of Oxford (UK) Zeljko Bozic, University of Zagreb (Croatia) Raul Duarte Salgueiral Gomes Campilho, Instituto Superior de Engenharia do Porto (Portugal) Demircan Canadinç, Koç University (Türkiye) Yoon-Suk Chang, Kyung Hee University (South Korea) Alan Cocks, University of Oxford (UK) Demirkan Çöker, Middle East Technical University (Türkiye) Kemal Davut, İzmir Institute of Technology (Türkiye) 5
Laura De Lorenzis, ETH Zürich (Switzerland) Eralp Demir, University of Oxford (UK) Mehmet Dördüncü, Erciyes University (Türkiye) Fionn Dunne, Imperial College London (UK) Mert Efe, Pacific Northwest National Laboratory (USA) Somnath Ghosh, Johns Hopkins University (USA) Ercan Gurses, Middle East Technical University (Türkiye) Anne Habraken, University of Liège (Belgium) Johan Hoefnagels, Eindhoven University of Technology (The Netherlands) Francesco Iacoviello, Università degli studi di Cassino e del Lazio Meridionale (Italy) Kaan Inal, University of Waterloo (Canada) Ali Javili, Bilkent University (Türkiye) Björn Kiefer, TU Bergakademie Freiberg (Germany) Benjamin Klusemann, Leuphana University of Lüneburg (Germany) Alexander M. Korsunsky, University of Oxford (UK) Giovanni Lancioni, Università Politecnica delle Marche (Italy) Łukasz Madej, AGH University of Science and Technology (Poland) Erdogan Madenci, The University of Arizona (USA) Lorenzo Malerba, CIEMAT (Spain) Hiroyuki Miyamoto, Doshisha University (Japan) David Morin, Norwegian University of Sciences and Technology (Norway) Phu Nguyen, Monash University (Australia) Kim Lau Nielsen, Technical University of Denmark (Denmark) Aida Nonn, OTH Regensburg (Germany) Deniz Öztürk, Johns Hopkins University (USA) Emilio Martínez Pañeda, University of Oxford (UK) Minh-Son Pham, Imperial College London (UK) Dierk Raabe, Max-Planck-Institut für Eisenforschung (Germany) Timon Rabczuk, Bauhaus University Weimar (Germany) Daniel Rittel, Technion - Israel Institute of Technology (Israel) Stefan Sandfeld, Forschungszentrum Jülich (Germany) Maxime Sauzay, CEA SACLAY (France) Alexandar Sedmak, University of Belgrade (Serbia) Huseyin Sehitoglu, University of Illinois at Urbana-Champaign (USA) Alexey Shutov, Lavrentyev Institute of Hydrodynamics (Russia) Caner Şimşir, Middle East Technical University (Türkiye) Reza Talemi, KU Leuven (Belgium) Cem Tasan, Massachusetts Institute of Technology (USA) Erman Tekkaya, TU Dortmund University (Germany) Cihan Tekoglu, TOBB University of Economics and Technology (Türkiye) Dmitry Terentyev, SCK•CEN (Belgium) Ton Van Den Boogaard, University of Twente (The Netherlands) 6
Denizhan Yavas, Lamar University (USA) Okan Yılmaz, ArcelorMittal Global R&D Gent - OCAS NV (Belgium) 7
Keynote Lectures Damage and fracture in deformation of materials and deformationbased manufacturing M. W. Fu∗ Department of Mechanical Engineering, Research Institute for Advanced Manufacturing, The Hong Kong Polytechnic University, Hong Kong, China ∗ mmmwfu@polyu.edu.hk Keywords: Void initiation and growth, damage and fracture, damage criteria and prediction. Deformation of materials and deformation-based manufacturing, viz., materials forming, are respectively the most practical engineering activity and the efficient manufacturing process, while the latter is widely employed to fabricate net-shape or near-net-shape parts via plastic deformation of materials. From manufacturing aspect, this traditional manufacturing process of metal forming has been being revitalized as many attractive advantages and uniqueness such as high productivity, superior mechanical properties, excellent material utilization, low production cost, and being able to fabricate the complex geometries and features of deformed parts, etc., cannot be replaced by other manufacturing processes. In this process, the design of deformed parts, forming process and tooling, defect prediction and avoidance, and product quality assurance and control are becoming more and more critical. All of these activities need to consider the damage and fracture in the deformation process of materials. Therefore, a scientific insight into the formation and occurrence of damage and fracture and an in-depth understanding of their mechanism and behaviors are crucial. In this talk, the mechanisms of the initiation, coalesce, growth of voids in the plastic deformation of materials, the formation and occurrence of damage and fracture, and their mechanisms, behaviors, and prediction and avoidance via experiment and simulation will be presented. The talk will thus give an overview of the state-of-the-art in damage and fracture research. 8
Stress redistribution in dwell fatigue of titanium alloy from in-situ characterisation and crystal plasticity modelling F. Dunne∗, Y. Cao, Y. Liu Department of Mechanical Engineering, Imperial College London, SW7 2AZ, UK ∗ fionn.dunne@imperial.ac.uk Keywords: Dwell fatigue, Titanium alloys, Crystal plasticity Cold dwell fatigue in Titanium aero-engine alloys is the degradation and failure process in which microcracks, or facets, nucleate typically within 15◦ of basal planes of (hard) HCP grains orientated with their c-axes at or about parallel to principal stress direction. A key driving force has been argued, through use of crystal plasticity (CP) modelling methods [1], to be creep deformation in an adjacent (soft) grain well-orientated for slip leading to stress redistribution onto the hard grain which occurs during cycle hold times (the dwell period), and over progressive cycling [2]. In addition, dwell facet nucleation and growth has been found to be associated with macrozones (or ‘MTRs’) which are millimetre-sized polycrystal regions with strong texture [2]. So far as we are aware, the key mechanistic argument for soft-grain creep and load shedding onto an adjacent hard grain have not yet been demonstrated or measured in experiment. The work presented in this paper addresses this important absence. Titanium alloy Ti-6Al-4V samples containing macrozones have been characterized with EBSD and speckled to facilitate DIC displacement measurement to allow in-situ full-field spatial intramacrozone strain measurement in three-point bend test samples under dwell fatigue loading. A novel (but with simplifications) methodology to extract out spatial elastic strains, and hence stresses with knowledge of anisotropic stiffnesses, at peak load at the beginning and end of the cyclic dwell period is presented and supported by considerations of stress equilibrium checks and CP modelling. Hence, full-field intra-macrozone stresses both during dwell periods and over cycles of fatigue loading have been obtained and are presented. Both soft-grain creep and redistribution of stress (load shedding) onto hard grains during the load hold time have been observed and quantified, and the associated dwell time constant for 66% of redistribution to have occurred has also been quantified, thus addressing the importance of the duration of the cycle dwell period. In addition, the in-situ DIC studies have allowed full-field strain and stress quantification over multiple cycles such that the cyclic change to redistributed stresses from cycle to cycle has also been quantified. The experimental observations reinforce that the hold period in dwell fatigue of Ti alloys does generate creep and load shedding and that cycling progressively drives up the stresses on the hard macrozones thus supporting many of the previous hypotheses from CP modelling. A quantitative assessment of how well CP models reflect experimental measurements of stress redistribution onto hard grains is also discussed. References [1] Hasija V, Ghosh S, Mills MJ, Joseph DS (2003). Deformation and creep modeling in poly9
crystalline Ti-6Al alloys. Acta Mater, 51(15), 4533–49. [2] Liu, Y, Dunne, FPE (2021). The Mechanistic Link between Macrozones and Dwell Fatigue in Titanium Alloys. Intl. Jnl. Fatigue. 142, 105971. 10
Parametrically-Upscaled Constitutive Model (PUCM) and Crack Nucleation Model (PUCNM) for Fatigue Predictions in Ti Alloys S. Ghosh∗, S. Kotha, D. Ozturk, G. Weber Department of Civil & Systems Engineering, Mechanical Engineering and Materials Science & Engineering, Johns Hopkins University, Baltimore, Maryland, USA ∗ sghosh20@jhu.edu Keywords: Parametric Upscaling, RAMPS, Fatigue Crack Nucleation This talk will give an overview of the Parametrically Upscaled Constitutive Model (PUCM) and Parametrically Upscaled Crack Nucleation Model (PUCNM) for Ti alloys [1-6], whose polycrystalline microstructures include micro-texture regions (MTRs). The micromechanics-informed PUCMs differ from conventional phenomenological models in their unambiguous depiction of constitutive parameters and their dependencies. The PUCMs are thermodynamically consistent, macroscopic constitutive models, whose coefficients are explicit functions of Representative Aggregated Microstructural Parameters (RAMPs), representing statistical distributions of morphological and crystallographic descriptors of the microstructure, e.g., texture and grain size distributions. The microstructure-dependent constitutive parameter functions are effective for establishing connections between microstructure and relevant higher-scale material response. They enable computationally efficient simulations with significant speedup over detailed lower-scale models and conventional multi-scale models. Development of the PUCMs requires a comprehensive framework, involving material characterization, micromechanical analysis using calibrated models, identification of characteristic forms of constitutive relations, sensitivity analysis, computational homogenization, machine learning and validation with experimental data. Furthermore, the upscaling platform is coupled with uncertainty quantification (UQ) and propagation. The PUCM/PUCNM tool is used to predict deformation and fatigue crack nucleation in aerospace structures under monotonic and cyclic loading conditions. References [1] S. Kotha, D. Ozturk, and S. Ghosh. Parametrically homogenized constitutive models (PHCMs) from micromechanical crystal plasticity FE simulations, part I: Sensitivity analysis and parameter identification for titanium alloys. Int. J. Plast., 120:296–319, 2019. [2] S. Kotha, D. Ozturk, and S. Ghosh. Parametrically homogenized constitutive models (PHCMs) from micromechanical crystal plasticity FE simulations: Part II: Thermo-elasto-plastic model with experimental validation for titanium alloys. Int. J. Plast., 120:320–339, 2019. [3] S. Kotha, D. Ozturk, and S. Ghosh. Uncertainty-quantified parametrically homogenized constitutive models (UQ-PHCMs) for dual-phase α/β titanium alloys. npj Comput. Mater., 6(1):1–20, 2020. [4] D. Ozturk, S. Kotha, and S. Ghosh. An uncertainty quantification framework for multiscale parametrically homogenized constitutive models (PHCMs) of polycrystalline Ti alloys. Jour. Mech. Phys. Solids, 148:104294, 2021. [5] J. Shen, S. Kotha, R. Noraas, V. Venkatesh, and S. Ghosh. Developing parametrically up11
scaled constitutive and crack nucleation models for the α/β Ti64 alloy. Int. Jour. Plast., pp. 103182, 2022. 12
Simulations of the Directed Energy Deposition process to manufacture parts in M4 High Speed Steel A. M. Habraken1,2,∗, R. T. Jardin1, T. Q. D. Pham1,3, J. T. Tchuindjang4, R. Carrus5, V. Tuninetti6, L. Duchêne1, A. Mertens4, T.VHoang7, X.V. Tran3 1 Department ArGEnCo, MSM Unit, University of Liège, Allée de la Découverte, 9 B52/3, B 4000 Liège, Belgium 2 Fonds de la Recherche Scientifique de Belgique (F.R.S-FNRS), 6, rue d’Egmont B 1000 Bruxelles, Belgique 3 Institute of Strategy Development, Thu Dau Mot University, 75100 Binh Duong Province, Vietnam 4 Department A&M, MMS Unit, University of Liège, Allée de la Découverte, 9 B52/3, B 4000 Liège, Belgium 5 Sirris Research Centre (Liège), Rue Bois St-Jean,12, B-4102, Seraing, Belgium. 6 Department of Mechanical Engineering, Universidad de La Frontera, Avenida Francisco Salazar, 01145 Temuco, Chile. 7 Chair of Mathematics for Uncertainty Quantification, RWTH-Aachen University, 52056 Aachen, Germany ∗ anne.habraken@uliege.be Keywords: Deep Learning, High Speed Steel, Additive Manufacturing This lecture presents all the steps required to reach a framework for the robust optimization under uncertainty in the directed energy deposition (DED) of M4 High-Speed Steel [1]. These developments were applied to identify optimal process parameters for robust manufacturing of printed parts with a stationary melt pool depth and low consumed energy under uncertainty within the multiple layers of a bulk sample. Based on 2D finite element simulations validated by experiments [2], a surrogate model using a feedforward neural network (FFNN) was developed for a fast and accurate prediction of the temperature evolutions and the melting pool sizes in a metal bulk sample (3D horizontal layers) manufactured by the DED process. The uncertainty characterization and propagation within the process were studied in [3] and prepared the possible use of robust optimization. References [1] Pham, T.Q.D., Hoang, T.V., Tran, X.V., Fetni, S., Duchêne, L., Tran, H.S., Habraken, A.M., (2023). A framework for the robust optimization under uncertainty in additive manufacturing Journal of Manufacturing Processes,103, 53-63 [2] Jardin, R.T. Tchoufang Tchuindjang, J. Duchêne, L.,Tran, H.S., Hashemi, N., Carrus, R., Mertens, A., Habraken, A.M.(2019).Thermal histories and microstructures in Direct Energy Deposition of a High Speed Steel thick deposit, Mater. Lett. 236. [3] Pham, T.Q.D., Hoang, T.V., Tran, X.V., Fetni, S., Duchêne, L., Tran, H.S., Habraken, A.M., (2022). Characterization, propagation, and sensitivity analysis of uncertainties in the directed 13
energy deposition process using a deep learning-based surrogate model, Probabilistic Eng. Mech. 69 14
Fatigue crack propagation in laser peened materials: A holistic simulation approach B. Klusemann1,2,∗, S. Keller1, N. Kashaev1 1 Institute of Materials Mechanics, Helmholtz-Zentrum Hereon, Geesthacht, Germany 2 Institute for Production Technology and Systems, Leuphana University Lüneburg, Luneburg, Germany ∗ benjamin.klusemann@hereon.de Keywords: laser shock peening, fatigue crack growth, simulation Laser shock peening (LSP) is known as efficient modification technique to generate deep compressive residual stresses in metallic structures. These compressive residual stresses are capable to reduce the fatigue crack propagation (FCP) rate, which results in an extension of the structural lifetime and/or maintenance intervals in terms of a damage tolerant design philosophy. Considering that residual stresses are also in equilibrium, it is obvious that generated compressive residual stresses are accompanied by balancing tensile residual stresses. However, as tensile residual stresses are supposed to accelerate the FCP rate, the overall residual stress field has to be known, when modification techniques, such as LSP, are applied. To support our understanding of these phenomena, a holistic virtual twin [1] from LSP process simulation [2] to the prediction of FCP rate is set-up and used in a close linking with experiments. The underlying multi-step simulation approach consists of four steps: (i) LSP process simulation for a representative volume to predict resulting plastic strains; (ii) transfer and extrapolations of these plastic strains to a relatively large LSP-treated area; (iii) calculation of the overall residual stress field as well as the stress intensity factor (SIF) range and rate; (iv) estimation of the FCP rate based on FCP equations. An ‘experimental simulation’ validates the simulation chain, where calculated SIFs are applied to untreated material. The FCP rate of the untreated material and experimentally determined FCP rate of LSP-treated material agree well, which indicates the calculation of realistic SIFs. The study reveals also the contribution of crack closure [3] in terms of FCP retarding mechanism. References [1] S. Keller, M. Horstmann, N. Kashaev, B. Klusemann, “Experimentally validated multi-step simulation strategy to predict the fatigue crack propagation rate in residual stress fields after laser shock peening”, Int. J. Fatigue, vol. 124, pp. 265-267, 2019. [2] S. Keller, S. Chupakhin, P. Staron, E. Maawad, N. Kashaev, B. Klusemann, “Experimental and numerical investigation of residual stresses in laser shock peened AA2198”, J. Mater. Process. Tech., vol. 255, pp. 294-307, 2018. [3] S. Keller, M. Horstmann, V. Ventzke, N. Kashaev, B. Klusemann, “Experimental and numerical investigation of crack closure in residual stress fields generated by laser shock peening”, Eng. Fract. Mech., vol 221, 106630, 2019. 15
Spatially resolved eigenstrain analysis across the scales: methods, distributions, insights A. M. Korsunsky∗ Trinity College, University of Oxford, Broad St., Oxford OX1 3BH, UK ∗ alexander.korsunsky@trinity.ox.ac.uk Keywords: diffraction, strain tomography, stress classification, eigenstrain Deformation within hierarchically structured materials is characterized by the complexity that is related to the mechanisms, scale, and the tensorial nature of the eigenstrains (inherent strains) that represent ‘material memory’ of prior inelastic processes. Solid mechanics requirements of total strain compatibility and stress equilibrium link eigenstrain to the measurable distributions of elastic strains within the body. In the course of thermal, environmental and deformation processing of materials, eigenstrains may undergo evolution through plastic deformation, phase transformation, etc. Depending on the scale of consideration, eigenstrains may be associated lattice defects and distortions, slip bands, crack tip zones and other microstructural features. Although it may be possible to quantify eigenstrain distributions directly, in most practical cases they need to be deduced from residual elastic strains (r.e.s.) that can be assessed by non-destructive diffraction techniques or by material removal methods, such as hole drilling or sectioning. Digital Image Correlation (DIC) that has gained popularity as a means of experimental mapping of deformation is characterized by scale independence that allows its application to images obtained at different magnification using various microscopy techniques. A particular application of interest to the present topic is the micro-ring core milling (FIB-DIC for short) as a means of residual stress and eigenstrain evaluation. This approach has made it possible to probe residual stresses of Type I, II and III and to determine their statistical distributions in deformed metallic alloy samples for comparison with crystal plasticity FEM simulations [1]. The author will discuss the possible origins of the observation that elastic strains (and stresses) tend to obey gaussian statistical distributions, while plastic strain (eigenstrain) distributions tend to be lognormal [2]. References [1] Everaerts, J., Salvati, E., Uzun, F., Brandt, L.R., Zhang, H.J., Korsunsky, A.M. (2018) Separating macro-(Type I) and micro-(Type II+ III) residual stresses by ring-core FIB-DIC milling and eigenstrain modelling of a plastically bent titanium alloy bar, Acta Materialia, 156, 43-51. [2] Chen, J., Korsunsky, A.M. (2021) Why is local stress statistics normal, and strain lognormal? Materials & Design, 198, 109319. 16
Technical Sessions Hydrogen Assisted Cracking Through Mixed-Mode Hydrogen-Sensitive Cohesive Zone Model B. Tatli∗, I. E. Unsal, T. Yalçinkaya Department of Aerospace Engineering, Middle East Technical University, Ankara 06800, Türkiye ∗ btatli@metu.edu.tr Keywords: hydrogen induced fracture, cohesive zone modeling, hydrogen diffusion. Metals, particularly high-strength steels, are susceptible to the phenomenon known as hydrogen embrittlement. Hydrogen embrittlement is observed when the metal interacts with a hydrogenproducing environment, particularly intensified under conditions of high pressure and humidity. This interaction allows small hydrogen particles to readily diffuse into the metallic material and relocate within the crystal lattice. Consequently, under stresses below the yield point of metallic materials, both ductility and load-bearing capacity are significantly reduced, resulting in cracking and potentially catastrophic brittle failures. While extensive documentation exists on the micromechanical and physical aspects of the hydrogen-assisted fracture, a complete understanding is yet to be achieved. In this study, the constitutive J2 plasticity model is integrated with both a mixed-mode cohesive zone formulation, see [1] for an example study, and a multi-trap hydrogen transport model [2] to simulate the failure process. Unlike some of the literature studies [3], the presented model effectively couples the hydrogen transport model with the cohesive zone formulation to account for the effects resulting from the hydrogen redistribution during crack tip propagation. This approach also allows for the prediction of intergranular fracture and the precise representation of the material’s sensitivity to hydrogen content. To validate the results obtained from the integrated framework, numerical examples from the literature are analyzed, and comparisons are made with experimental data. References [1] Aydiner, I. U., Tatli, B., and Yalçinkaya, T. (2023). Micromechanical modeling of failure in dual phase steels. Material Research Proceedings, 28, 1443-1452. [2] Fernández-Sousa, R., Betegón, C., and Martínez-Pañeda, E. (2020). Analysis of the influence of microstructural traps on hydrogen assisted fatigue. Acta Mater., 199, 253-263. [3] Lin, M., Yu, H., Wang, X., Wang, R., Ding, Y., Alvaro, A., and Zhang, Z. (2022). A microstructure informed and mixed-mode cohesive zone approach to simulating hydrogen embrittlement. Int. J. Hydrog. Energy, 47(39), 17479-17493. 17
Unified Mechanics Theory: An Entropy-Based Uncertainty Quantification for Monotonic Tensile Failure of A36 Steel K. M. Asaali1, J. B. A. Agramon1, P. J. F. Chiong1, T. H. Asaali2, E. S. Cruz1, R. P. Gammag3 1 School of Civil, Environmental, and Geological Engineering, Mapúa University, City of Manila 1002, Philippines 2 Department of Mathematics, Tawi-Tawi Regional Agricultural College, Bongao, Tawi-Tawi 7500, Philippines 3 Department of Physics, Mapúa University, City of Manila 1002, Philippines Keywords: Newtonian Mechanics, Thermodynamics, Unified Mechanics Theory, 1-D analytical modelling, thermodynamic-frameworked continuum damage mechanics, monotonic tensile failure, tensile strength, A36 steel Tensile yielding and fracture failures occur as a result of plastic deformation, an irreversible degradation process, in a steel material. Historically, tensile failures in steel members have been predicted by analysing and designing structural members in accordance with the provisions of the structural building codes (e.g., National Structural Code of the Philippines or NSCP) or by extrapolating empirical curve-fitted models using phenomenological data on structural member failure. The design provisions of NSCP for structural members are also based on phenomenological data that went through laboratory trialand- error analyses. The current study contributes to the centennial effort of the scientists and physicists to unify Newtonian Mechanics and Thermodynamics and strengthen the proof for the applicability of the Unified Mechanics Theory in construction and structural engineering. The researchers employed the said theory to predict or quantify the failure uncertainty of A36 steel when subjected to monotonic tensile loading condition. Using one-dimensional analytical modelling, the unified mechanics theory was used to derive a onedimensional predictive model for failure prediction. The proposed analytical model was used to predict the A36 steel’s tensile strength. It is demonstrated in this study that using a simple predictive model based on the material’s fundamental equations derived by the researchers and thermodynamics associated with material degradation, the unified mechanics theory can be used to predict the tensile strength of an A36 steel. References [1] Basaran, C. (2021). Introduction to unified mechanics theory with applications. Switzerland: Springer Nature Switzerland AG. [2] Basaran, C., Nie, S. (2004). An irreversible thermodynamic theory for damage mechanics of solids. International Journal of Damage Mechanics, 13(3), 205-224. [3] Jamal M, N.B., Kumar, A., Lakshmana Rao, C., Basaran, C. (2020). Low cycle fatigue entropy life prediction using unified mechanics theory in ti-6al-4v alloys. Entropy, 22, 24. 18
Effect of Nozzle Diameter on Tensile and Fracture Behavior of 3DPrinted FDM-PLA Samples S. S. Hosseini1, A. Nabavi-Kivi1, M. R. Ayatollahi1,∗, M. Petru2 1 Fatigue and Fracture Research Laboratory, Center of Excellence in Experimental Solid Mechanics and Dynamics, School of Mechanical Engineering, Iran University of Science and Technology, Narmak 16846, Tehran, Iran 2 Faculty of Mechanical Engineering, Technical University of Liberec, Studentsk´a 2, 461 17, Liberec, Czech Republic ∗ m.ayat@iust.ac.ir Keywords: Fused Deposition Modeling (FDM), Nozzle diameter, Fracture resistance The Fused Deposition Modeling (FDM) technique is a subcategory of 3D printing processes that works by extruding a fine polymeric filament through a nozzle on the heated platform. Polylactic Acid (PLA) is among the mostly used materials in the FDM technique with good applicability in the medical industry [1]. In recent years, researchers have tried to figure out how the manufacturing processes in the FDM technique can influence the mechanical performance including the basic mechanical properties [2] as well as the fatigue and fracture behavior [3]. Most of the studied manufacturing parameters were raster angle, layer orientation and printing speed [4]. Meanwhile, little information about the effects of nozzle diameter on the mechanical properties of 3D printed polymers is available. Therefore, the current paper surveys the influence of nozzle diameter on the mechanical properties and mode I fracture behavior of FDM-PLA specimens. Four different nozzle diameters of 0.4, 0.6, 0.8, and 1 mm with two raster configurations of 0/90◦ and 45/-45◦ were considered. Dog-bone and Semi-Circular Bending (SCB) samples were designed and printed for tensile and fracture tests, respectively. Also, to evaluate the fracture resistance of FDM-PLA pre-cracked samples, the critical value of J-integral (Jc) was used and calculated through finite element analysis. The experimental results indicated that 1 mm nozzle diameter with the raster angle of 45/-45◦ could provide higher mechanical properties compared to other cases. This was also true for the fracture experiments where the SCB samples printed through the 1 mm nozzle diameter and 45/-45◦ raster orientation had the highest value of Jc (10400 J/m2). Besides, the paths of crack extension were monitored and discussed comprehensively. References [1] Ramesh, M and Panneerselvam, K. (2021). "Mechanical investigation and optimization of parameter selection for Nylon material processed by FDM," Mater. Today Proc., 46, 9303-9307. [2] Liu, J., Naeem, M. A., Al Kouzbary, M., Al Kouzbary, H., Shasmin, H. N., Arifin, N., ... & Abu Osman, N. A. (2023). Effect of Infill Parameters on the Compressive Strength of 3D-Printed Nylon-Based Material. Polymers, 15(2), 255. [3] Azadi, M., Dadashi, A., Dezianian, S., Kianifar, M., Torkaman, S., & Chiyani, M. (2021). 19
High-cycle bending fatigue properties of additive-manufactured ABS and PLA polymers fabricated by fused deposition modeling 3D-printing. Forces in Mechanics, 3, 100016. [4] Lee, E. H., Ahn, J. S., Lim, Y. J., Kwon, H. B., & Kim, M. J. (2022). Effect of layer thickness and printing orientation on the color stability and stainability of a 3D-printed resin material. The Journal of Prosthetic Dentistry, 127(5), 784-e1. 20
Experimental and numerical investigation of ductile damage and fracture under biaxially loaded tensile reverse loadings Z. Wei∗, S. Gerke, M. Brünig Institut für Mechanik und Statik, Universität der Bundeswehr München, Werner-Heisenberg-Weg 39, 85579 Neubiberg, Germany ∗ zhichao.wei@unibw.de Keywords: Biaxial experiment, Reverse loading, Ductile damage and fracture Although many studies on the behavior of metal sheets are based on experiments with uniaxially loaded specimens, the engineering structures are often imposed by multi-axial cyclic loading in manufacturing processes and applications. Therefore, biaxially loaded cruciform specimens are used to investigate the plastic, damage, and fracture behavior under monotonic proportional or non-proportional loading conditions [1-2]. Recently, it has been detected that the damage and fracture behavior is remarkably influenced by different low-cycles reverse loadings [3-4].This presentation deals with the experimental and numerical analysis of the plastic, damage, and fracture behavior caused by biaxial non-proportional tensile reverse loadings. A series of tensile reverse loading tests with biaxially loaded specimens superimposed by different shear preloads are performed during the experiments. Digital image correlation monitors and analyzes the global force-displacement behavior and the local strain fields. The various damage mechanisms are revealed through scanning electron microscopy of fractured surfaces. In the numerical part, an anisotropic elastic-plastic-damage two-surface uncoupled continuum model is utilized to predict material behavior in both macro- and micro-levels. The proposed material model provides accurate numerical results compared to the experimental ones. References [1] Raj, A., Verma, R. K., Singh, P. K., Shamshoddin, S., Biswas, P., & Narasimhan, K. (2022). Experimental and numerical investigation of differential hardening of cold rolled steel sheet under non-proportional loading using biaxial tensile test. International Journal of Plasticity, 154, 103297. [2] Brünig, M., Zistl, M., & Gerke, S. (2021). Numerical analysis of experiments on damage and fracture behavior of differently preloaded aluminum alloy specimens. Metals, 11(3), 381. [3] Wei, Z., Zistl, M., Gerke, S., & Brünig, M. (2022). Analysis of ductile damage and fracture under reverse l-oading. International Journal of Mechanical Sciences, 228, 107476. [4] Kanvinde, A. M., & Deierlein, G. G. (2007). Cyclic void growth model to assess ductile fracture initiation in structural steels due to ultra low cycle fatigue. Journal of Engineering Mechanics, 133(6), 701-712. 21
Nomenclature of Yield Criteria for Isotropic Materials H. Altenbach1,∗, V.A. Kolupaev2, P.L. Rosendahl3 1 Lehrstuhl für Technische Mechanik, Institut für Mechanik (IFME), Fakultät für Maschinenbau, Ottovon-Guericke-Universität Magdeburg, Universitätsplatz 2, D-39106 Magdeburg, Germany 2 Mechanics & Simulation, Department of Plastics, Fraunhofer Institute for Structural Durability and System Reliability (LBF), Schloßgartenstr. 6, D-64289 Darmstadt, Germany 3 Structural Mechanics and Additive Manufacturing, Institut für Statik und Konstruktion ISM+D, Technische Universität Darmstadt, Karolinenplatz 5, D-64289 Darmstadt ∗ holm.altenbach@ovgu.de Keywords: π plane, limit surface, systematization The choice of the yield criterion is crucial for reliable material description and design results. Numerous yield criteria proposed over the last 150 years are hardly used because their utility is not obvious. In addition, the cost of material testing, parameter adjustment, and complexity of implementation often outweigh the benefits of accurate material description. There is no clear procedure for selecting the best criterion for a particular application. The mathematical expressions for the yield criteria can be very different, making it difficult to compare them directly for the best fit. However, possible shapes of yield criteria in the π-plane are limited by the convexity bounds. The upper and lower bounds are referred to as extreme yield figures. Extreme figures can take the shape of isogonal and isotoxal polygons of trigonal or hexagonal symmetry. Regular polygons are limit cases of the extreme yield figures [1, 3]. This work proposes a unique nomenclature of the criteria based on their geometric shapes and orientation in the π-plane, e.g., VON MISES⃝, IVLEVˆ3,MARIOTTE3, TRESCAˆ6, SCHMIDTISHLINSKY 6 , SOKOLOVSKY 1ˆ2, among others. Circumflexˆand macron refer to an upward pointing tip or upward facing flat base of the regular shape in the π-plane, respectively. The generalized yield criteria can be characterized by the regular polygons and the circle in the π-plane that they contain. There are known six criteria that are of interest: ˆ3−ˆ6−3, ˆ3−⃝−3, ˆ3−6−3, ˆ6−1ˆ2−6, ˆ6−⃝−6, ˆ6−12−6. The criteria involving less than three of the basic geometries are edge cases and excluded from our discussion. Based on the introduced nomenclature, a verification standard for the yield criteria is developed and the number of the useful yield criteria is reduced to a few manageable cases. The C0 and C1 continuous criteria that contain five basic geometries ˆ3−ˆ6|⃝|6−3 and ˆ6−1ˆ2|⃝|12−6, and that satisfy the plausibility conditions [1] are significant. Their usage eliminates the need to develop and select specific criteria for classes of materials like alloys, polymers, etc. References [1] Altenbach, H., Kolupaev, V. A., General Forms of Limit Surface: Application for Isotropic Materials, in Altenbach, H., Beitelschmidt, M., Kästner, M. et al. (Eds.), Material Modeling and Structural Mechanics, Advanced Structured Materials, v. 161, Springer, Cham, 1-76, 2022. 22
[2] Kolupaev, V. A., Equivalent Stress Concept for Limit State Analysis, Springer, Cham, 2018. [3] Rosendahl, P. L. and Kolupaev, V A. and Altenbach, H., Extreme Yield Figures for Universal Strength Criteria, in Altenbach, H. and Öchsner, A. (Eds.), State of the Art and Future Trends in Material Modeling, Advanced Structured Materials, v. 100, Springer, Cham, 259-324, 2019. 23
Fuel Tank Design at Inner Pressure V.A. Kolupaev1,∗, M. Bulla2 1 Mechanics & Simulation, Department of Plastics, Fraunhofer Institute for Structural Durability and System Reliability (LBF), Schloßgartenstr. 6, D-64289 Darmstadt, Germany 2 Altair Engineering Inc., Nasdaq, Josef-Lammerting-Allee 10, D-50933 Cologne, Germany ∗ vladimir.kolupaev@lbf.fraunhofer.de Keywords: Burzyński-plane, triaxiality, Poisson’s ratio Multiaxial stress states in components are evaluated using stress analysis methods: stress angle, triaxiality factor, equivalent stress. However, when designing with VON MISES criterion adjusted based on the tensile test, under-dimensioning may occur for multiaxial tensile loading. Such loading cases are crucial in the design of the tanks under internal pressure. Generalized strength criteria require data from additional tests: shear, compression, equibiaxial tension, etc. However, these tests are often costly and may be subject to excessive scatter, sometimes beyond the accuracy of the design. The basic idea of this work is to define the safety at the multiaxial tensile loading in the absence of measured data. For this purpose, the deviation 5. . . 10% from the predicted value with VON MISES criterion is set at the balanced biaxial tensile loading. The required parameter is calculated using this deviation and can be expressed as a plastic POISSON’s ratio. Three adapted strength criteria are implemented for design: BERG, original HUBER and modified HUBER [1, 2] These criteria describe pressure-insensitivity under compression but limit the hydrostatic tensile stress. The limit surfaces represent the scaled VON MISES cylinder in the principal stress space C1 -capped with SCHLEICHER ellipsoid at the different cross sections I 1 =σ T 0 (uniaxial tension, BERG criterion: no uniaxial compression / uniaxial tension difference), I1 =σ S 30 (shear, HUBER criterion) or I1 =σ C 60 (uniaxial compression, modified HUBER criterion). The subscripts describe the stress angle θ of the corresponding loads. The stress analysis is performed in a post processor of commercial FEM software Altair Radioss® and Ansys®. In order to determine the weak points of the designed component, the deviation of the proposed stress criteria from VON MISES criterion is varied in the dimensioning phase. The impact of this method is demonstrated with an automobile fuel tank made of HDPE. The selection of the criterion depends on the modelling concept: conservative (BERG), universal (HUBER) or progressive (modified HUBER). Based on the introduced criteria, optimization of thermoplastic components can lead to new design concepts. Our evaluations with the discussed criteria have shown, that approx. 10% deviation from the predicted value with VON MISES criterion at the equibiaxial tension can be recommended as a first step in the pre-design. These results are transferrable to similar components. 24
References [1] Bulla, M., Kolupaev, V.A., Stress Analysis in Design with Plastics: Accessible method with huge impact, Kautschuk, Gummi Kunststoffe KGK, Hüthig GmbH, 74(5), 2021, 32-39. [2] Kolupaev, V. A., Equivalent Stress Concept for Limit State Analysis, Springer, Cham, 2018. 25
Fixture for 2D Compression Test with Uniaxial Testing Machine V.A. Kolupaev∗ Mechanics & Simulation, Department of Plastics, Fraunhofer Institute for Structural Durability and System Reliability (LBF), Schloßgartenstr. 6, D-64289 Darmstadt, Germany ∗ vladimir.kolupaev@lbf.fraunhofer.de Keywords: Design, Equibiaxial compression, Optimization 2D compression test is essential for design of critical parts. Equibiaxial compression test can be easily performed using a circumferential clamp (Figure 1). The load F is applied using a uniaxial testing machine. The eccentricity ex is utilized to obtain uniform stress distribution. The gap ey is estimated from the uniaxial compression test data. Specimen "biting" at the overhang area of the gap is minimized with a compensator. Friction is reduced by lubricating the contact area. Partially overlapping curved sheets can be placed in the contact area. Figure 1: 2D compression test: 1 - compression clamp, 2 - specimen, 3 - compensator. When designing the fixture with FEM, the optimization objectives include the following: • simultaneous plastification of the clamp in the entire contact area and • equal change of the inner radii of the clamp ∆at the selected angles φ during loading. The recommended thickness of a metal or polymer foam specimen is b =d/2. For the testing of sheet specimens made e.g., of fiber-reinforced polymers, a groove is provided on the grips in the contact area to ensure specimen fixation and stability during loading. The depth of the groove is matched to the thickness of the specimen. The clamp material is plasticized during the test. The reuse of the clamp after the test with subsequent mechanical treatment is under discussion. The specimen is speckled with a statistically distributed black & white pattern. This allows the two-dimensional strain on the specimen surface to be evaluated by digital image correlation as 26
function of the load F and the gap closure ey in a subsequent post-processing step. Stress calculations are performed using reverse engineering. The experiments can be carried out in a thermal chamber. The obtained material data are crucial for model selection and parameter adjustment in responsible modelling [1]. References [1] Kolupaev, V. A., Equivalent Stress Concept for Limit State Analysis, Springer, Cham, 2018. 27
Assessing Fatigue Life Characteristics of API X65 Steel under the Effects of Corrosion in Deep-Sea Environment M.A. Khan1, S.S.K. Singh1,∗, S. Abdullah1, M. Bashir2 1 Department of Mechanical and Manufacturing Engineering, Faculty of Engineering and Built Environment, Universiti Kebangsaan Malaysia, 43600 UKM Bangi, Selangor, Malaysia 2 School of Engineering, Faculty of Engineering and Technology, Liverpool John Moores University, Liverpool, United Kingdom ∗ salvinder@ukm.edu.my Keywords: Fatigue, Stress-Life, Durability The aim of this study is to assess the fatigue life characteristics based on the effectsof corrosion for API X65 steel under deep-sea environment. In the oil and gas industry,assessing the pipeline failure caused by corrosion is important especially when dealing withcrack growth that is induced by internal and external cyclic loads. Likewise, the strength ofoffshore pipelines is affected by the presence of cracks due to the variation of loads, materialproperties and the corrosive effects due to salinity and pH values. During the service life ofsubsea pipelines, corrosion fatigue crack growth is a common occurrence that often results ina decrease in their strength and loss of asset integrity which frequently leads to pipelinecracking [1,2]. Therefore, evaluating the durability of pipelines is essential because of theinterdependence between corrosion fatigue, pipeline material properties, crack dimensions,geometric design and load ratios [3]. Tensile test is carried out for welded and non-weldedspecimens that were not submerged and submerged for 48 hours in sea water condition. Thisis based on the salinity and pH test values of the seawater condition sourced from the coastalarea of Port Dickson, Malaysia. In addition, the microscopic features and chemical compositionwere examined through FESEM and EDX on the fractured surface of the pipeline material. Afatigue stress-life (S-N) curve is plotted using the Basquin equation based on values obtainedfrom the UTS/mechanical testing. These results calculated using the Basquin equation, it wasfound that the endurance limit of API X65 steel is 276.3MPa. Finite element modelling for thecompact tension was carried out for three different load ratios (0.1, 0.4, and 0.7). The finiteelement analysis of the pre-cracked CT specimen shows that the stress intensity factor isproportionally linear with the length of crack and load ratio. Hence, this study confirms thatthe FE analysis provides a relevant alternative approach for fatigue life estimation of API X65steel using crack growth as a function of corrosion fatigue mechanism. References [1] Cheng, A., & Chen, N. Z. (2022). Structural integrity assessment for deep-water subseapipelines. International Journal of Pressure Vessels and Piping, 199, 104711. [2] Guo, Y., Shao, Y., Gao, X., Li, T., Zhong, Y., & Luo, X. (2022). Corrosion fatigue crack growthof serviced API 5L X56 submarine pipeline. Ocean Engineering, 256, 111502. [3] Lyathakula, K. R., & Yuan, F. G. (2021). A probabilistic fatigue life prediction for adhesivelybonded joints via ANNs-based hybrid model. International Journal of Fatigue, 151, 106352. 28
Hot-Dip Aluminizing of Flow-formed AISI 4140 Steel A. Karakaş1,2,∗, M. Baydoğan2 1 Repkon Machine and Tool Industry, Istanbul 34980, Türkiye 2 Department of Metallurgical and Materials Engineering, Istanbul Technical University, Istanbul 34469, Türkiye ∗ aptullah.karakas@repkon.com.tr Keywords: Hot-dip aluminizing, Flow forming, Microstructure Flow forming is a cold deformation technique for the manufacturing of axisymmetric components. During the flow forming, a rotating initial tube (preform) is pushed by rollers through the thickness direction of the tube. After the process, the tube elongates along the flow forming direction with a corresponding reduction in its thickness. Cold plastic deformations recognizably cause increasing lattice imperfections such as point defects and dislocations in the structure, which could then have an effect on diffusion characteristics of the material [1-2]. In order to explore such an effect of flow forming, a flow formed AISI 4140 steel and an annealed 4140 steel were subjected to the HDA process in a molten Al7020 bath at 750◦ C for 4 minutes, and a subsequent diffusion annealing was performed at 800◦C, and their coating characteristics such as coating thickness and hardness were compared. The results indicated that the coating thickness of the flow formed samples was higher (80 µm) than that of the annealed sample (µm) after the HDA process. Diffusion annealing increased the coating thickness of both samples five times, reaching 400 µm and 250 µmfor the flow formed and the annealed samples, respectively. Comparing the measured thickness of the coatings revealed that flow forming accelerates diffusion during the HDA process, probably due to the defect structure induced by the flow forming. On the other hand, the coating hardness was in between 1000-1100 HV for both samples, implying that the initial condition of the sample does not have a remarkable effect on hardness after the HDA process. References [1] Karakaş, A., Fenercioğlu, T.O., Yalçinkaya, T. (2021), The influence of flow forming on the precipitation characteristics of Al2024 alloys, Materials Letters, Vol. 299, 130066. [2] Yürektürk, Y. and Baydoğan, M. (2018), Characterization of ferritic ductile iron subjected to successive aluminizing and austempering, Surface and Coatings Technology, Vol. 347, Pages 142-149. 29
Crack Formation after Diffusion Annealing of Hot-Dip Aluminized AISI 4140 Steel A. Karakaş1,2,∗, M. Baydoğan2 1 Repkon Machine and Tool Industry, Istanbul 34980, Türkiye 2 Department of Metallurgical and Materials Engineering, Istanbul Technical University, Istanbul 34469, Türkiye ∗ aptullah.karakas@repkon.com.tr Keywords: Hot-dipped aluminizing, Microstructure, Crack formation Hot dip aluminizing (HDD) is a surface treatment process in which a metal substrate is coated with a layer of aluminum to enhance its corrosion ad oxidation resistance. However, crack formation can occur during the HDA process possibly due to presence of thermal stresses within the coatings arising from mismatch in thermal expansion coefficients of the aluminide layers and the substrate, brittle nature of the aluminide phases and process parameters. Therefore, optimization of the HDA process parameters such as temperature, dipping time and cooling rate from the dipping temperature might help reducing the possibility of crack formation. Additionally, subsequent diffusion annealing might have an effect on crack formation and overall integrity of the aluminized coating [1-2]. In this study, an AISI 4140 low alloyed steel was subjected to the HDA process in an Al-11wt.% Si bath at 750◦C for 9 minutes and subsequent annealing was performed at 750◦C, 850◦C and 950◦C. Examination of the diffusion annealed samples indicated that there were some cracks within the coatings of the samples, which were annealed at 750◦C and 850◦C, while there was no cracking on the surface of sample annealed at 950◦C. The results were comparatively evaluated by considering the process parameters and the characteristics of the aluminide layers, and was attributed to the formation of ductile and brittle aluminide phases depending on the applied annealing temperature. References [1] Cheng, W.J., Wang, C.J. (2010), Observation of high-temperature phase transformation in the Si-modified aluminide coating on mild steel using EBSD, Materials Characterization, Vol. 61, 467-473. [2] Springer,H, Kostka,A, Payton,E, Raabe,D, Kaysser-Pyzalla,A„ Eggeler,G.(2011), On the formation and growth of intermetallic phases during interdiffusion between low-carbon steel and aluminum alloys, Acta Materialia, Vol. 59, 1586-1600. 30
Watching the grain boundaries slide S. Wei, C. C. Tasan∗ Department of Materials Science and Engineering, Massachusetts Institute of Technology, Cambridge, MA02139, U.S.A. ∗ tasan@mit.edu Keywords: intergranular fracture; thermal activation; in situ microscopy Unlike their strengthening contributions at ambient temperature, grain boundaries are the Achilles’ Heel of polycrystalline alloys at elevated temperatures. The enhanced atomic motion diversifies the plasticity micro-mechanisms, complicating the resultant damage and fracture mechanisms. Grain boundary sliding is one such example. Provided the extensive efforts using post-mortem characterizations, time-resolved studies of grain boundary sliding are scarce, and unambiguous understanding of its role in plastic strain accommodation and damage nucleation is still lacking. In this talk, we will present an in situ SEM-based high-temperature investigation of grain boundary sliding in a model Co-based alloy [1,2], emphasizing the mechanistic insights into plastic flow and damage inception. We will show that grain boundary sliding is not only correlated with a rare serrated-to-stable plastic flow transition, but also accommodates more than 20 % plastic strain at 750 ◦C under a strain rate of 10−4 s−1. With the aid of electron channeling contrast imaging, we also underpin the involvement of dislocation cross-slip in accommodating grain boundary sliding. Based on the testing conditions and the experimental observations, a series of deformation microevents are identified and their roles in intergranular damage nucleation will also be discussed. References [1] Wei, S.L., Tasan, C.C. (2023). On the plastic deformation of a CoCrFeNiW-C alloy at elevated temperatures: Part II. Grain boundary sliding and damage mechanisms. Acta Materialia, 252, 118898. [2] Wei, S.L., Moriarty, D.P., Xu, M., LeBeau, J.M., Tasan, C.C. (2023). On the plastic deformation of a CoCrFeNiW-C alloy at elevated temperatures: Part I. Serrated plastic flow and its latent dynamics. Acta Materialia, 242 118430. 31
